ECG monitor is a precision medical instruments which widely used in hospitals. The rechargeable battery is the power source of ECG monitor .It made up of Lithium Polymer  Battery. This type of battery with longer cycle life and high energy system.In addition, the lithium polymer battery without memory function, this is important to the battery life.



Battery specification

Model No.： PL954374-1S1P

Nominal voltage：3.7V

Rated capacity： 3200mAh

Continuous discharge current: 0.2C

Maximum discharge current: 1C

Working temperature：charge：0~45℃;  discharge ：-20~60℃

Dimension：MAX 10.7*45.55*79.5mm

Battery resistance：≤200mΩ

PCBA：IC-R5402N187KD+ MOS-AO8810

Overcharge voltage/cell: 4.25±0.025V

Over discharge voltage : 3.0±0.06V

Over current ： 3~7A

Picture of the Cell(Lithium polymer cell)

Maintenance and use of battery:

1.To prevent battery from damage or fire, do not contact the battery electrode

   with sheet-metal

2.For longer battery life, please use the original charger.

3.To reduce risk of fire or burns,do not attempt to open or disassemble the battery.

  Do not crush or dispose of in fire .

4..Storage：-20~60℃ (within 1 month)

          -20~30℃(less than 6 months)
